电压等级：300/500V
测试电压：2000V/5min(AC)
固定敷设：5D
移动敷设：7.5D
固定敷设：-20°C～80°C
移动安装：-15°C～80°C
耐油性：普通
耐候性：耐UV，适合户内使用
阻燃特性：符合IEC60332-1
架空速度：3m/S
滑行速度：2m/S
加速度：20m/S²
|
规格 |
标称外径 |
最大外径 |
电缆总重量 |
|
|
芯数*截面mm² |
mm |
mm |
KG/KM |
|
|
2*0.25 |
4*48/0.08 |
5.0 |
5.7 |
40 |
|
3*0.25 |
3*48/0.08 |
5.1 |
5.9 |
45 |
|
4*0.25 |
4*48/0.08 |
5.4 |
6.2 |
51 |
|
5*0.25 |
5*48/0.08 |
5.9 |
6.7 |
61 |
|
6*0.25 |
6*48/0.08 |
6.4 |
8.2 |
71 |
|
7*0.25 |
7*48/0.08 |
6.7 |
7.6 |
78 |
|
8*0.25 |
8*48/0.08 |
7.1 |
8.0 |
87 |
|
10*0.25 |
10*48/0.08 |
7.9 |
8.8 |
100 |
|
12*0.25 |
12*48/0.08 |
8.8 |
9.7 |
122 |
|
14*0.25 |
14*48/0.08 |
9.3 |
10.2 |
136 |
|
2*0.34 |
2*19/0.15 |
4.3 |
4.9 |
60 |
|
3*0.34 |
3*19/0.15 |
4.5 |
5.1 |
72 |
|
4*0.34 |
4*19/0.15 |
4.9 |
5.5 |
82 |
|
5*0.34 |
5*19/0.15 |
5.2 |
5.9 |
93 |
|
6*0.34 |
6*19/0.15 |
5.8 |
6.5 |
104 |
|
7*0.34 |
7*19/0.15 |
6.2 |
6.9 |
119 |
|
8*0.34 |
8*19/0.15 |
6.7 |
7.5 |
138 |
|
10*0.34 |
10*19/0.15 |
8.9 |
9.9 |
160 |
|
12*0.34 |
12*19/0.15 |
9.0 |
10.0 |
172 |
|
14*0.34 |
14*19/0.15 |
10.1 |
11.2 |
209 |
|
16*0.34 |
16*19/0.15 |
11.8 |
13.0 |
225 |
|
18*0.34 |
18*19/0.15 |
12.9 |
14.3 |
235 |
|
20*0.34 |
20*19/0.15 |
13.0 |
14.4 |
269 |
|
24*0.34 |
24*19/0.15 |
14.2 |
15.7 |
315 |
|
25*0.34 |
25*19/0.15 |
15.4 |
17.0 |
320 |
|
30*0.34 |
30*19/0.15 |
16.7 |
18.3 |
372 |
|
36*0.34 |
36*19/0.15 |
18.0 |
19.8 |
428 |
|
2*0.5 |
2*28/0.15 |
6.8 |
7.7 |
73 |
|
3*0.5 |
3*28/0.15 |
7.1 |
8.0 |
84 |
|
4*0.5 |
4*28/0.15 |
7.6 |
8.5 |
96 |
|
5*0.5 |
5*28/0.15 |
8.0 |
8.9 |
110 |
|
6*0.5 |
6*28/0.15 |
9.0 |
9.9 |
134 |
|
7*0.5 |
7*28/0.15 |
9.5 |
10.4 |
148 |
|
8*0.5 |
8*28/0.15 |
10.2 |
11.2 |
166 |
|
10*0.5 |
10*28/0.15 |
11.6 |
12.8 |
199 |
|
12*0.5 |
12*28/0.15 |
11.8 |
13.0 |
216 |
|
14*0.5 |
14*28/0.15 |
13.3 |
14.6 |
256 |
|
16*0.5 |
16*28/0.15 |
14.4 |
15.9 |
289 |
|
18*0.5 |
18*28/0.15 |
14.6 |
16.1 |
295 |
|
20*0.5 |
20*28/0.15 |
15.6 |
17.2 |
33/8 |
|
24*0.5 |
24*28/0.15 |
17.1 |
18.8 |
395 |
|
25*0.5 |
25*28/0.15 |
17.1 |
18.9 |
402 |
|
30*0.5 |
30*28/0.15 |
18.7 |
20.6 |
485 |
|
36*0.5 |
36*28/0.15 |
20.7 |
22.7 |
576 |
|
2*0.75 |
2*24/0.20 |
7.3 |
8.1 |
83 |
|
3*0.75 |
3*24/0.20 |
7.6 |
8.4 |
97 |
|
4*0.75 |
4*24/0.20 |
8.1 |
9.0 |
113 |
|
5*0.75 |
5*24/0.20 |
9.0 |
9.9 |
140 |
|
6*0.75 |
6*24/0.20 |
9.6 |
10.5 |
158 |
|
7*0.75 |
7*24/0.20 |
10.2 |
11.2 |
177 |
|
8*0.75 |
8*24/0.20 |
10.9 |
12.0 |
198 |
|
10*0.75 |
10*24/0.20 |
12.5 |
13.8 |
239 |
|
12*0.75 |
12*24/0.20 |
12.7 |
14.0 |
262 |
|
14*0.75 |
14*24/0.20 |
14.8 |
16.3 |
323 |
|
16*0.75 |
16*24/0.20 |
15.6 |
17.2 |
351 |
|
18*0.75 |
18*24/0.20 |
15.8 |
17.4 |
370 |
|
20*0.75 |
20*24/0.20 |
17.2 |
18.9 |
421 |
|
24*0.75 |
24*24/0.20 |
18.8 |
20.7 |
507 |
|
25*0.75 |
25*24/0.20 |
18.9 |
020.8 |
516 |
|
30*0.75 |
30*24/0.20 |
20.8 |
22.9 |
617 |
|
36*0.75 |
36*24/0.20 |
22.8 |
25.0 |
722 |
|
2*1.0 |
2*32/0.20 |
7.8 |
8.6 |
96 |
|
3*1.0 |
3*32/0.20 |
8.1 |
9.0 |
114 |
|
4*1.0 |
4*32/0.20 |
9.1 |
10.0 |
143 |
|
5*1.0 |
5*32/0.20 |
9.7 |
10.7 |
165 |
|
6*1.0 |
6*32/0.20 |
10.4 |
11.4 |
188 |
|
7*1.0 |
7*32/0.20 |
11.3 |
12.4 |
217 |
|
8*1.0 |
8*32/0.20 |
12.1 |
13.4 |
243 |
|
10*1.0 |
10*32/0.20 |
13.9 |
15.3 |
295 |
|
12*1.0 |
12*32/0.20 |
14.2 |
15.6 |
324 |
|
14*1.0 |
14*32/0.20 |
16.3 |
17.9 |
391 |
|
16*1.0 |
16*32/0.20 |
17.4 |
19.2 |
431 |
|
18*1.0 |
18*32/0.20 |
17.6 |
19.4 |
458 |
|
20*1.0 |
20*32/0.20 |
19.3 |
21.3 |
542 |
|
24*1.0 |
32*32/0.20 |
21.1 |
23.2 |
637 |
|
25*1.0 |
25*32/0.20 |
21.2 |
23.4 |
648 |
|
30*1.0 |
30*32/0.20 |
23.2 |
25.5 |
764 |
|
36*1.0 |
36*32/0.20 |
25.4 |
27.9 |
889 |
|
2*1.5 |
2*48/0.20 |
9.0 |
9.9 |
126 |
|
3*1.5 |
3*48/0.20 |
9.4 |
10.3 |
151 |
|
4*1.5 |
4*48/0.20 |
10.14 |
11.1 |
179 |
|
5*1.5 |
5*48/0.20 |
10.8 |
11.9 |
210 |
|
6*1.5 |
6*48/0.20 |
11.8 |
13.0 |
246 |
|
7*1.5 |
7*48/0.20 |
12.6 |
13.8 |
276 |
|
8*1.5 |
8*48/0.20 |
13.6 |
15.0 |
313 |
|
10*1.5 |
10*48/0.20 |
15.9 |
17.5 |
387 |
|
12*1.5 |
12*48/0.20 |
16.2 |
17.8 |
428 |
|
14*1.5 |
14*48/0.20 |
18.9 |
20.8 |
541 |
|
16*1.5 |
16*48/0.20 |
20.4 |
22.4 |
605 |
|
18*1.5 |
18*48/0.20 |
20.6 |
22.6 |
632 |
|
20*1.5 |
20*48/0.20 |
22.3 |
24.6 |
728 |
|
24*1.5 |
48*48/0.20 |
24.2 |
26.7 |
843 |
|
25*1.5 |
25*48/0.20 |
24.4 |
26.8 |
861 |
|
30*1.5 |
30*48/0.20 |
26.9 |
29.5 |
1023 |
|
36*1.5 |
36*48/0.20 |
29.4 |
32.3 |
1205 |
|
2*2.5 |
2*77/0.20 |
10.0 |
11.0 |
158 |
|
3*2.5 |
3*77/0.20 |
10.5 |
11.5 |
193 |
|
4*2.5 |
4*77/0.20 |
11.5 |
12.6 |
239 |
|
5*2.5 |
5*77/0.20 |
12.4 |
13.6 |
280 |
|
6*2.5 |
6*77/0.20 |
13.3 |
14.6 |
325 |
|
7*2.5 |
7*77/0.20 |
14.6 |
16.1 |
383 |
|
8*2.5 |
8*77/0.20 |
15.9 |
17.5 |
433 |
|
10*2.5 |
10*77/0.20 |
18.3 |
20.2 |
526 |
|
12*2.5 |
12*77/0.20 |
18.8 |
20.7 |
609 |
|
14*2.5 |
14*77/0.20 |
22.2 |
24.4 |
755 |
|
16*2.5 |
16*77/0.20 |
23.5 |
25.8 |
822 |
|
18*2.5 |
18*77/0.20 |
23.7 |
26.0 |
881 |
|
20*2.5 |
20*77/0.20 |
26.0 |
28.6 |
1007 |
|
24*2.5 |
77*77/0.20 |
28.5 |
31.3 |
1183 |
|
25*2.5 |
25*77/0.20 |
28.6 |
31.5 |
1214 |
|
30*2.5 |
30*77/0.20 |
32.1 |
35.3 |
1531 |
|
36*2.5 |
36*77/0.20 |
35.1 |
38.6 |
1794 |
产品规格不限于以上所列，可根据客户要求定制；
截面和芯数可根据客户要求定制；
更特殊场合的电缆可根据场合定制。
