DJYPVP copper core XLPE insulated copper wire braided split screen total screen computer cable
  • Product Details Introduction
  • Product specifications
use:

A large number of data processing equipment rooms, intelligent traffic control systems, modern storage systems (such as power stations, hydropower stations, sewage treatment plants, chemical plants and other high-capacity computer systems) measurement and control engineering, suitable for dry or wet indoor fixed installation.



Use characteristics:
The long-term working temperature of the cable should not exceed 70 °C. The twisted structure can decouple the circuit (crosstalk effect), can withstand moderate mechanical stress, and has flame retardancy: flame retardant self-extinguishing conforms to IEC 60332-1-2.

model:

DJYPVP、ZR-DJYVP、DJYPVPR22、DJYPVPR、DJYPVPR2V



Voltage level:

450/750V



specification:

2×0.75~2×6mm²

3×0.75~3×6mm²

4×0.75~4×6mm²

5×0.75~5×6mm²

7×0.75~7×6mm²

8×0.75~8×6mm²

10×0.75~10×6mm²

12×0.75~12×6mm²

14×0.75~14×6mm²

16×0.75~16×2.5mm²

19×0.75~19×2.5mm²

24×0.75~24×2.5mm²

27×0.75~27×2.5mm²

30×0.75~30×2.5mm²

37×0.75~37×2.5mm²

44×0.75~44×2.5mm²

52×0.75~52×2.5mm²

61×0.75~61×2.5mm²
